High-performance thermal interface materials designed to efficiently transfer heat away from critical electronic components in automotive, EV, and electronics applications.
Our Thermal Interface Pads fill air gaps between heat-generating components and heat sinks, ensuring efficient thermal transfer while maintaining electrical insulation. Available in silicone and non-silicone constructions with a range of thermal conductivities, thicknesses, and compliance levels.
Typical specification range — custom grades available to specific application requirements. Contact our team for material certification data.
| Material | Silicone / Non-silicone (polyurethane, acrylic) |
|---|---|
| Thermal Conductivity | 1.0 – 8.0 W/m·K (typical) |
| Thickness Range | 0.5 mm – 5.0 mm |
| Hardness | 20 – 70 Shore 00 (typical) |
| Breakdown Voltage | > 6 kV (typical) |
| Volume Resistivity | > 10¹² O·cm |
| Temperature Range | -40°C to +200°C |
| Flame Rating | UL 94 V-0 |
| Delivery Form | Die-cut pads / sheets / rolls |
| Certifications | IATF 16949:2016; RoHS; UL recognised |
Efficiently transfers heat from components to heat sinks, maintaining stable operating temperatures.
Conforms to surface irregularities and fills air gaps between mating surfaces for optimal thermal transfer.
Provides electrical isolation between components and heat sinks, preventing short circuits and leakage.
